Nr. 14122057-030 - RTK Lithuania Sales

BRAND	RTK
Product	Nr. 14122057-030
Description	complete control valve
Internal code	IMP4189010
Custom code	84818059
Technical specification	Pneumatic control valve - series PV 6211 two-way design nominal diameter DN 20, pressure rating PN 25 body made of spheroidal graphite iron EN-GJS-400-18-LT flanges according to DIN spindle packing: chevron rings PTFE/graphite characteristic / flow direction: equal % / normal parabolic cone, metal sealing kvs-value = 3,7 m³/h, stroke 25 mm seat diameter 12 mm surface treatment with zinc dust primary coat max. allowed pressure according to DIN EN 1092 max. allowed temperature TS 250 °C Pneumatic actuator - type ST 6135.B6-6G air supply max. 6 barg diaphragm area 280 cm² spring range 0.8..3.0 bar / max. stroke 35 mm safety position: spring to close (diverting valve: port A, mixing valve: port B) accessories: - electropneumatic positioner, type SR 3300 L 2-wire connection input signal 4..20 mA at 0 % input, valve closed - pressure gauge - module for position feedback, 2-wire connection output 4..20 mA (electrically isolated)

Please Contact Us to Order to offer competitive prices and delivery time for RTK - Nr. 14122057-030 complete control valve number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
