PV 6211 for 321062/02 - RTK Lithuania Sales

BRAND	RTK
Product	PV 6211 for 321062/02
Description	pneumatic control valve
Internal code	IMP4902326
Technical specification	Pneumatic control valve - PV 6211 series in continuous form nominal size DN 32, nominal pressure PN 25 Housing material ductile iron EN-GJS-400-18-LT Flanges with DIN sealing surface Spindle sealing: PTFE/carbon roof collars Characteristic/flow rate: equal percent/below the cone parabolic cone, metallic sealing Kvs value = 15 m³/h, stroke 30 mm Seat diameter 32 mm Surface treatment with zinc dust primer CE marking in accordance with Pressure Equipment Directive (PED) max. allowable pressure in accordance with DIN EN 1092 max. allowable temperature TS 250 °C pneumatic actuator - type ST 6135.B6-6G Supply air pressure max. 6 barue Membrane area 280 cm² Spring range 0.8.. 3.0 bar/max. stroke 35 mm Safety position: spring closes (Distribution valve: port A, mixing valve: port B)

Please Contact Us to Order to offer competitive prices and delivery time for RTK - PV 6211 for 321062/02 pneumatic control valve number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.
