PV 6211 for 9062289/010 - RTK Lithuania Sales

BRAND	RTK
Product	PV 6211 for 9062289/010
Description	pneumatic control valve
Internal code	IMP4902322
Technical specification	Pneumatic control valve - PV 6211 series in continuous form nominal size DN 50, nominal pressure PN 16 Housing material grey cast iron EN-GJL-250 Flanges with DIN sealing surface Spindle sealing: PTFE/carbon roof collars Characteristic/flow rate: equal percent/below the cone parabolic cone, metallic sealing Kvs value = 18 m³/h, stroke 25 mm Seat diameter 25 mm Surface treatment with zinc dust primer CE marking in accordance with Pressure Equipment Directive (PED) pneumatic actuator - type ST 6135.B6-6G Supply air pressure max. 6 barue Membrane area 280 cm² Spring range 0.8.. 3.0 bar/max. stroke 35 mm Safety position: spring closes (Distribution valve: port A, mixing valve: port B) additional equipment: - Electropneum. Positioner, type SR 6136 (SIPART PS2) 2/3/4-wire connection Input 4.. 20 mA at 0% input, valve closed

Please Contact Us to Order to offer competitive prices and delivery time for RTK - PV 6211 for 9062289/010 pneumatic control valve number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
