Buy DM0803-AAA01A0E0HJE-309mm from Interroll in Lithuania

BRAND	Interroll
Product	DM0803-AAA01A0E0HJE-309mm
Internal code	IMP5060528
Technical specification	MI-DM0080 Product name DM 0080 3-phase asynchronous Protection level IP 69K Tube length (SL) 302.0 mm Drum width (FW) 309.0 mm Installation length (EL/LW/BF) 314.0 mm Overall axle length (AGL) 339.0 mm Power 140 W coil number of pins 2 Torque [Nm] 13.8 Band tensile force 339 N Gear ratio (i) 31.35 Gear material name Steel: 16MnCr5/AISI 5115 Speed at frequency 1 0.38 m/s Frequency 1 50 Hz external connection diagram M34 high voltage 400 V low voltage 230 V Rated current, high voltage 0.38 A rated current, low voltage 0.65 A Speed at frequency 2 0.47 m/s Frequency 2 60 Hz high voltage 2 460 V low voltage 2 230 V Steel pipe material: St37-2/AISI 1015 Pipe diameter (A) 81.5 mm Pipe diameter (B) 80.5 mm Convex tube shape (standard) Cover A version Standard cover B version Standard Cover A Material ALUMINUM: EN-AC43400/AL239 Cover B Material ALUMINUM: EN-AC43400/AL239 Shaft A version standard Ø17mm shaft B version standard Ø17mm Shaft A Material stainless steel: 1.4305/303 Shaft B Material stainless steel: 1.4305/303 Wave A key area (F) 13.5 mm Wave B key area (F) 13.5 mm Wave A key face length (C) 12.5 mm Wave B key face length (C) 12.5 mm Oil type mineral oil viscosity 68 Electrical connection straight screw connection Elek. Connection material brass CuZn39pb3/MS58 Power cable length 10.0 m Power cable type unshielded; not halogen-free min. ambient temperature 2 °C max. ambient temperature 40 °C

Discover the superior quality and performance of the Interroll DM0803-AAA01A0E0HJE-309mm with Impexron GMBH in Lithuania . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.

The DM0803-AAA01A0E0HJE-309mm is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.

Key Features of DM0803-AAA01A0E0HJE-309mm :

High Performance: Engineered to deliver exceptional results.
Durable Construction: Built with high-quality materials for long-lasting use.
Innovative Design: Incorporates the latest technology for enhanced efficiency.
Cost-Effective: Offers great value for money with competitive pricing.

At Impexron GMBH , we offer the DM0803-AAA01A0E0HJE-309mm at competitive prices and with the fastest delivery times across Lithuania . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.

Why Choose Impexron GMBH ?

Expert Assistance: Get help from our knowledgeable team for all your product-related questions.
Competitive Prices: We offer some of the best prices in the market.
Fast Delivery: Benefit from our efficient delivery network for quick turnaround times.
Customer Satisfaction: Our commitment to customer service ensures a great buying experience.

Get Your Quote Today! Ready to enhance your operations with the DM0803-AAA01A0E0HJE-309mm ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.

Important Notice: While we supply Interroll products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
