RD-EC5000 RL:383 - Interroll Lithuania Sales

BRAND	Interroll
Product	RD-EC5000 RL:383
Internal code	IMP4734457
Technical specification	Item number: RD-51DC-2000000-R21-S02 Roll length (RL) 383 mm Installation length (EL): 419 mm Protection class: IP54 UL certification Yes Power 35 W Nominal voltage 24 V Interface: analog Gear ratio 18 AREA OF APPLICATION (temperature) Default, 0 - 40°C Cable length: 500.0 mm Nominal torque [Nm]: 0.89 Galvanised pipe material Outer tube diameter: 50.0 mm Tube wall thickness: 1.5 mm Drive element: Poly-Vee drive head Number of drive elements: 9 Rib nut mounting material Axle diameter bearing size: 11.0 mm Axle design. Non-cable side: spring axle Axle material: stainless steel Axle shape bearing size: hexagonal Ball bearing material: stainless steel Mat. Tube/rubber coating: PVC Tube/rubber coating thickness: 2.0 mm Hardness of hose/rubber coating: 62+5° Shore Oberfl. Tube/rubber coating: smooth Tube/rubber coating colour: grey Number of hoses/rubber coating: 1 Tube size A (RL): 6.0 mm Tube size D (RL): 6.0 mm small diameter: 0.0 mm large diameter: 0.0 mm

Please Contact Us to Order to offer competitive prices and delivery time for Interroll - RD-EC5000 RL:383 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
