MI-DM0113 DM1133-AAA0BA0ERMGA-457mm - Interroll Lithuania Sales

BRAND	Interroll
Product	MI-DM0113 DM1133-AAA0BA0ERMGA-457mm
Internal code	IMP4729683
Technical specification	Product name DM 0113 Asynchronous 3-phase Degree of protection IP 69K Tube length (SL) 450.0 mm Drum width (FW) 457.0 mm Installation length (EL/LW/BF) 470.0 mm Overall axle length (AGL) 520.0 mm Power 300 W Number of pins 4 windings Torque [Nm] 119.1 Belt pull force 2,098 N Gear ratio (i) 63.00 Transmission Material name Cast-Iron: GGG-40 Speed at frequency 1 0.13 m/s Frequency 1 50 Hz external connection diagram M45 high voltage 400 V low voltage 230 V Rated current, high voltage 0.75 A rated current, low voltage 1.30 A Speed at frequency 2 0.16 m/s Frequency 2 60 Hz high voltage 2 460 V low voltage 2 230 V Steel pipe material: St37-2/AISI 1015 Tube diameter (A) 113.5 mm Tube diameter (B) 112.0 mm Spherical tube shape (standard) Cover A standard version Cover B version Standard Cover A Material ALU: EN-AC43400/AL239 Cover B Material ALUMINUM: EN-AC43400/AL239 Shaft A version standard Ø30mm Shaft B version standard Ø30mm Shaft A material stainless steel: 1.4305/303 Shaft B material stainless steel: 1.4305/303 Wave A wrench surface width (F) 25.0 mm Wave B wrench surface width (F) 25.0 mm Wave A wrench surface length (C) 25.0 mm Wave B wrench surface length (C) 25.0 mm Oil type mineral oil Electrical connection terminal box Elek. Connection material ALU AlSi10Mg (Fe)/AL239

Please Contact Us to Order to offer competitive prices and delivery time for Interroll - MI-DM0113 DM1133-AAA0BA0ERMGA-457mm number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.
