BRAND | Interroll |
Product | MI-DM0165 DM1653-ASM1BE0GGLDH-417mm |
Internal code | IMP4837593 |
Technical specification | Product Name DM 0165 Asynchronous 3-Phase Certification cRUus UL Certified IP Rating 69K Shell Length (SL) 16.14 " Face Width (FW) 16.42 " Between Frames (EL/LW/BF) 17.72 " Overall Length (AGL) 19.69 " Poles 4 Power 1.00 hp Torque [Nm] 258.0 Belt Pull Force 3,000 N Gear Ratio (i) 62.37 Gear Material Casted Steel: GGG-40 Velocity at Frequency 1 46 fpm Frequency 1 60 Hz External Wiring Diagram M31 High Voltage 460 V Current, High Voltage 1.50 A Velocity at Frequency 2 39 fpm Frequency 2 50 Hz High Voltage 2 400 V Low Voltage 2 0 V Shell Material Stainl. Steel: 1.4301 / 304 Shell Diameter (A) 6.77 " Shell Diameter (B) 6.69 " Shell Shape Crowned (Standard) Shell Option Type Smooth Lagging Coating / Treatment Material NBR Rubber Coating Material Hardness 70 Shore A Coating Colour White Coating Application Type Hot Lagging |
Please Contact Us to Order to offer competitive prices and delivery time for Interroll - MI-DM0165 DM1653-ASM1BE0GGLDH-417mm number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
