MI-DM0113 DM1133-A++03B0E9FHJ-257mm - Interroll Lithuania Sales

BRAND	Interroll
Product	MI-DM0113 DM1133-A++03B0E9FHJ-257mm
Internal code	IMP4681298
Technical specification	Product name DM 0113 Asynchronous 3-phase Protection grade IP 69K Tube length (SL) 250.0 mm Drum width (FW) 257.0 mm Installation length (EL/LW/BF) 270.0 mm Total axle length (AGL) 320.0 mm Power 160 W Winding number of poles 4 Torque [Nm] 19.6 Pulling force 303 N Gear ratio (i) 20.00 Gear material name Cast-iron: GGG-40 Speed at frequency 1 0.47 m/s Frequency 1 50 Hz external connection diagram M34 high voltage 400 V low voltage 230 V Rated current, high voltage 0.54 A rated current, low voltage 0.94 A Speed at frequency 2 0.57 m/s Frequency 2 60 Hz high voltage 2 460 V low voltage 2 230 V Steel tube material: St37-2/AISI 1015 Tube diameter (A) 129.5 mm Tube diameter (B) 128.0 mm Ball tube shape (standard) Pipe option type smooth rubber coating Coating material NBR rubber coating coating hardness 70 Shore A Coating color white coating process hot vulcanized Pipe radial groove 1 shape special groove parallel \|_\| Tube slot 1 width at the top (T) 16.0 mm Tube slot 1 width below (U) 16.0 mm Pipe slot 1 depth (S) 7.0 mm Pipe slot 1 center gauge 1 125.0 mm Cover A standard version Lid B standard design Cover A Material ALU: EN-AC43400/AL239 Cover B Material ALU: EN-AC43400/ AL239 Shaft A version Standard Ø25mm Shaft B version Standard Ø25mm Shaft A Material stainless steel: 1.4305/303 Shaft B Material stainless steel: 1.4305/303 Wave A end. Area width (F) 20.0 mm Wave B end. Area width (F) 20.0 mm Wave A end surface length (C) 25.0 mm Wave B end surface length (C) 25.0 mm oil type synthetic food oil Electrical connection Elbow fitting Elek. Polybutylene terephthalate material connection Power cable length 5.0 m Screened power cable type; not halogen-free

Please Contact Us to Order to offer competitive prices and delivery time for Interroll - MI-DM0113 DM1133-A++03B0E9FHJ-257mm number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
