| BRAND | Interroll |
| Product | DM 0138 (MI-DM0138 DM1383-A7E13B0E5MAA-507mm) |
| Description | motor |
| Internal code | IMP4178721 |
| Technical specification | Product Name DM 0138 Asynchronous 3-Phase Degree of protection IP 69K SL Tube length 500.0 mm end face width between covers 507.0 mm EL/LW/BF installation length 530.0 mm AGL axle total length 580.0 mm Power: 370 W, winding number of pins 4 Torque [Nm] 144.0 belt tensile force 1.839 N Gear Ratio 63.00 Transmission Type Cast Iron: GGG-40 Speed at frequency 1 0.18 m/s Frequency 1 50 Hz external connection diagram M45 high voltage 400 V low voltage 230 V Rated current, high voltage 1.01 A Rated current, low voltage 1.74 A Speed at frequency 2 0.22 m/s Frequency 2 60 Hz high voltage 2 460 V low voltage 2 230 V Stainless steel pipe material: 1.4301/304 Tube diameter A 156.6 mm pipe diameter B 156.6 mm Pipe shape profiled Tube Option Type UNI Series MPB Number of teeth 10 Coating material NBR rubber coating hardness 70 Shore A Coating paint white coating process hot vulcanized Cover A Standard Cover B Standard Standard Lid A Material Stainless Steel: 1.4305/303 Lid B Stainless Steel Material: 1.4305/303 Shaft A version Replacement 138i Standard Shaft B Replacement Design 138i Standard Shaft A Material Stainless Steel: 1.4305/303 Shaft B Material Stainless Steel: 1.4305/303 Shaft A Diameter 30.0 mm Shaft B Diameter 30.0 mm Wave A wrench width 20.0 mm Shaft B spanner width 20.0 mm Wave A key area length 25.0 mm shaft B spanner length 25.0 mm Oil type synthetic food oil Electrical connection terminal box Elek. Connection material stainless steel: 1.4301/304 |
Please Contact Us to Order to offer competitive prices and delivery time for Interroll - DM 0138 (MI-DM0138 DM1383-A7E13B0E5MAA-507mm) motor number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
