MI-DL0113 DL1131-BDN0AD01TFSC-712mm  - Interroll Lithuania  Sales

BRAND Interroll
Product MI-DL0113 DL1131-BDN0AD01TFSC-712mm
Internal code IMP4262752
Technical specification DL 0113 Asynchronous 1-Phase UL Approval CRUUs UL Certified Degree of protection IP 66 Tube length (SL) 690.0 mm drum width (FW) 712.0 mm Installation length (EL/LW/BF) 718.0 mm total axle length (AGL) 758.0 mm Power 110 W, winding number of pins 4 Torque [Nm] 16.5 belt tensile force 268 N Gear ratio (i) 23.96 Speed at frequency 1 0.35 m/s Frequency 1 50 Hz external connection diagram E10 high voltage 230 V Rated current, high voltage 1.04 A Steel pipe material: St37-2/AISI 1015 Tube diameter (A) 123.0 mm pipe diameter (B) 123.0 mm Tube shape cylindrical Pipe Option Type Smooth Rubber Coating material NBR rubber coating hardness 70 Shore A Coating paint white coating process hot vulcanized Cover A Material ALU EN-AC44300/AL230 Cover B Material ALU EN-AC44300/AL230 Cap A Material Aluminium Cap B Material Aluminium Cap A Diameter 35.0 mm Cap B Diameter 35.0 mm Cap A spanner width 21.0 mm cap B spanner width 21.0 mm Cap A spanner length 20.0 mm cap B spanner length 20.0 mm Oil type mineral oil Electrical connection butt plate with cable slot Power cable length: 3.0 m, power cable type, unshielded; not halogen-free

Please Contact Us to Order to offer competitive prices and delivery time for Interroll - MI-DL0113 DL1131-BDN0AD01TFSC-712mm number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
