W20112J009F04 - Delta Controls Lithuania Sales

BRAND	Delta Controls
Product	W20112J009F04
Description	PRESSURE SWITCH
Internal code	IMP4476563
Technical specification	set point of 3 bar g rising as per provided Serial No: W138820/1*1. W - Pressure die-cast in zinc alloy, General Purpose Weatherproof. For outdoor industrial use, IP66/NEMA 4 for electrical switching and IP54/NEMA 3 for pneumatic switching. (IP54/NEMA 3 Only with ranges BC,C6,E1,E8) 201 - Fixed switching differential. Bellows/Capsule Stack prime mover for applications up to 75 bar For maximum working pressure consult technical data sheet. 1 - 22mm Dia clearance hole for 20mm Or 3/4 inch O/Dia Conduit 2 - Stainless Steel all welded fabrication J0 - 0.2 to 4 bar G. & Pmax. 8 bar G. 09 - Double Pole Double Throw. Environmentally Sealed 5 Amps @110/250 Volts AC/ 5 Amps @ 30 Volts DC. F - 1/4-18 NPT Int. direct Process connection. 0 - No additional options required. 4 - Process connection prepared for Oxygen service. 0000 - No nonstandard requirements

Please Contact Us to Order to offer competitive prices and delivery time for Delta Controls - W20112J009F04 PRESSURE SWITCH number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
