BRAND | Owon |
Product | CP-07+ |
Description | DC/AC current probe |
Internal code | IMP4770462 |
Technical specification | Specifications Testing range 400 mA - 4 A Resolution 0.1 mA Bandwidth DC - 1 MHz Clamp size 5 mm (max) Auto-zero Yes DC current: Range (accuracy) Sensitivity 400mA (1.5% + 5d) 1mV/1mA 4A (1.5% + 5d) 1mV/10mA AC current: Range Sensitivity 400mA (2% + 5d) 1mV/1mA 4A (2% + 5d) 1mV/10mA Connector BNC Power supply 9V 6F22 Battery Dimensions 215 x 36 x 58 mm |
Please Contact Us to Order to offer competitive prices and delivery time for Owon - CP-07+ DC/AC current probe number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
