BRAND | Warex |
Product | Type DKZ103 DN 600 |
Description | butterfly valve |
Internal code | IMP4494511 |
Custom code | 84818085 |
Technical specification | Basis: preliminary order 150032/2013 for medium: air Properties: pourable, chemically neutral, not prone to caking Working pressure: 0.5 bar. Max. allowed Working pressure: 1.0 bar (PS) MAWP (Note: MAWP = Ausl. pressure) Operating temp.: 0 °C... +60 °C (Ts) MAWT Ambient temp.: 0 °C... +50 °C (Ta) Explosion protection: no requirement Article number WX2000 installation length 110 mm for clamping between flanges according to EN 1092, PN 6 housing made of silumin Flap disc made of steel/WCB Shafts made of stainless steel 1.4057 or higher quality Shaft sealing by means of O-rings Shaft bearing in brass - bushing sealing collar made of NBR black firmly glued in the housing further attachments: further attachments: Pneumatic rotary actuator RC 265 DA double-acting 1296 Nm required control pressure 6.0 bar Solenoid valve 5/2 way function Norgren 2623077.3037 48 V DC, 1.7 W, IP 65 Namur version Limit switch box with 2 sensors Turck NI 4-M12-AZ 31X NO contact, 20-250 V AC/ 10-300 V DC, IP 67 AC/DC version built into Makrolon housing 175/80/55 and wired to terminal strip |
Please Contact Us to Order to offer competitive prices and delivery time for Warex - Type DKZ103 DN 600 butterfly valve number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
