BRAND	Steimel
Product	ASF2-8R---171344L
Description	Gear pump unit
Internal code	IMP4161570
Custom code	84136039
Technical specification	A-SF2/8R-VLFM 1,2kW - S3, 1500/1800, 400-440V, 50/60Hz, IP55, Iso.F, B5 Gear pump unit: SF 2/8 R - VLFM Article no. : ASF2-8R --- 171344L Dimension sheet: DPA052-090LFM - 32 Spare parts list: DET052008R --- 165L Suction and pressure connection: G 1 / SAE 1 Housing parts: EN-GJL-250 (GG-25) Pinion shafts, noiseless : 16MnCrS5, egh., Helical teeth, Storage: multilayer MD Shaft sealing: radial shaft sealing ring Elastomers: FKM Pumped medium: lubricating oil Viscosity: 30-5000 cSt Temperature: approx. 10-60 ° C Delivery rate: approx. 8 / 9.6 l / min. Pressure: max. 20 bar Speed: 1450/1740 rpm. Direction of rotation: left to right Test run: yes, with HLPD 46 Coupling: BKUA040-1424-301 Pump bracket with foot: BLF052200110LA21 Three-phase motor: LDM090-04-227 (Birkenbeul) Motor data: Power: 1.2 kW S3-60% Speed: 1500/1800 rpm Voltage: 440-440 volts Frequency: 50/60 Hz Efficiency class: IE2 Protection class: IP 55 Insulation class: F Design: B 5 : Aggregate painting: primed RAL 6011 (HDO058) Type plate: ETY924-D-E - PE02 Direction of rotation arrow: 1x IQL253 on the pump and 1x glued to the fan cover! (Direction arrow in Casting removed)

Please Contact Us to Order to offer competitive prices and delivery time for Steimel - ASF2-8R---171344L Gear pump unit number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.
