BRAND | Uwt |
Product | RN 3001A W11EA1C3A |
Description | Level control |
Internal code | IMP4799838 |
Custom code | 90318080 |
Technical specification | Pos.10: Type [A] RN 3001 Pos.20: Certificate [W] ATEX II 1/2D Ex ta/tb IIIC T! Da/Db Post.30: Process temperature [1] max. +80°C (176°F) Pos.40: Process overpressure [1] max. 0.8 bar (11.60 psi) Pos.50: Power supply [E] 24 V DC 2.5 W Post.60: Process connection [A] Thread G 1½”, DIN 228 Pos.70: Material process with [1] aluminum Pos.80: Length of extension L [C] 200 mm (7.87') Pos.90: Material of extension L [3] stainless steel Pos.100: Measuring vane [A] boot-shaped 40 x 98 mm (1.57 x 3.86') stainless steel, for 1½ 'socket Pos.200: Local Certificates [0] without Pos.320: Bearing at tube end [0] without |
Please Contact Us to Order to offer competitive prices and delivery time for Uwt - RN 3001A W11EA1C3A Level control number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
