BRAND | Hanovia |
Product | PharmaLine D AF H 0005 |
Description | UV system |
Internal code | IMP4433201 |
Technical specification | with 1 low-pressure amalgam lamp, complete with 316L stainless steel chamber, control cabinet, UV monitor, 0.38 μm internal surface finish, and Tri-clamp connections. Design Data • Application: Pharma • Water Type: Ultrapure Water • Pre-treatment: Filtration (recommended) • Design Flow Rate: 6 m³/h • UV Transmittance (T 10): 98% • UV Dose: 26 mJ/cm² (average) Technical Data – PharmaLine D AF H 0005 i) Design Flow Rate: 6 m³/h ii) UV Transmittance (T 10): 98% (assumed) iii) UV Dose: 26 mJ/cm² (average) at the end of lamp life iv) UV Lamp Type: Hanovia low-pressure amalgam lamp v) Power Consumption per Lamp: 80 W vi) Number of Lamps: 1 vii) Expected Lamp Life: 12,000 hours viii) Chamber Material: Stainless Steel 316L / 1.4404 ix) Connections: 1½” (DN 40) Tri-clamp x) Pressure Rating: 10 bar xi) Cabinet Material: Polyester coated carbon steel xii) Supply Voltage: 230 V ±10% / 115 V ±10% - 50/60 Hz xiii) Standard Cable Length:5 m |
Please Contact Us to Order to offer competitive prices and delivery time for Hanovia - PharmaLine D AF H 0005 UV system number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
