BRAND | HIMMEL |
Product | C10-G56M4 |
Description | Worm gear motor |
Internal code | IMP4046681 |
Custom code | 85015100 |
Technical specification | HIMMEL® worm gear motor C10-G56M4 CSA-C/US-Ausführung Getriebebauart / Type: HIMMEL®-Schneckengetriebemotor / HIMMEL®-worm gear Getriebetyp / Type: C10-G56M4 Maßbild / Dimension sheet: C14 Abtriebsdrehzahl / Output speed [1/min; 1/rpm]: 3.30//4.00 Übersetzung / Ratio [i]: 418.73 Farbe / colour: RAL 5015 Himmelblau 2K / Sky blue 2K-PUR Korrosivitätskategorie / corrosion protection: C1: i.A.a. DIN EN ISO 12944-2 Schichtdicke Lack/ paint layer thickness [µm]: 50-80 Schutzart / protection class: IP55 Bauform / mounting position: V5-00-AB Abtriebsmoment / Output torque [Nm]: 30.0//31.0 Drehrichtung Abtrieb/Output direction of rotation: rechts / right Abtriebswelle Getriebe / Output shaft [mm; Zoll]: V20x36 2. Wellenende Getriebe / 2.Output shaft [mm; Zoll]: V16x28 Lagerung Getriebe / Bearing: radial verstaerkt / radially strengthened bearings Ölart / Oil type: CLP PG 460 Synth.oil Ölmenge / Oil quantity [l]: 0.22 Wellenwerkstoff / Shaft material: 42CrMo4 Abdichtung Getriebe / Sealing: Wellendichtring (WDR) Viton / shaft seal ring Viton Elektrische Ausführung / Elektrical design: CE Polzahl / Poles: 4 Nennfrequenz / Nominal frequency [Hz]: 50//60 Nennspannung / Nominalvoltage [V]: 200-208/346-360 Schaltung / Wiring: S100//S100 (D/Y//D/Y) Nennleistung / Nominalpower [kW]: 0.037/0.045 Motordrehzahl nenn / Motor speed nom. [1/rpm]: 1420//1690 Nennstrom / Nominal current In [A]: 0.54/0.31//0.39/0.23 CosPhi / CosPhi: 0.50//0.63 KK-Lage / Terminal box position: 3C KK-Ausführung / Terminal box type: Aluminium / aluminium Wicklungsschutz / Motor protector: ohne / without Abtriebswelle Motor / Output shaft [mm; Zoll]: V11x24.5 Abdichtung Motor / Sealing motor: Viton / viton Isolationsklasse / Insulation class: F Betriebsart / Duty type: S1 Lüfter / Fan: Kunststoff / plastic |
Please Contact Us to Order to offer competitive prices and delivery time for HIMMEL - C10-G56M4 Worm gear motor number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
