BRAND | Omega |
Product | PX656-02D1 |
Description | Highly Accurate, Low Pressure Industrial Transmitter |
Internal code | IMP4459503 |
Technical specification | Excitation: 12 to 36 Vdc Output: 4 to 20 mA (2 wire) Operating Temp: -29 to 85°C (-20 to 185°F) Compensated Temp: -18 to 72°C (0 to 160°F) Thermal Effects: Zero: 0.015% FS/°F Span: 0.015% FS/°F Proof Pressure: 10 psi Burst Pressure: 50 psi Static Pressure: 100 psi Sensor Type: Capacitance Max Loop Resistance: (Supply voltage - 12) x 50 Ω Calibration Report: NIST calibration at 25, 50, 75 and 100% FS; upscale and downscale provided Response Time: 250 ms Wetted Parts: Dry, clean non-corrosive gases only Enclosure: NEMA 4X (IP65); 137 L x 76 W x 64 mm D (5.4 x 3 x 2.5") Pressure Port: ¼ NPTF Electrical Conn: Screw terminal (two ½ NPTF conduit) |
Discover the superior quality and performance of the Omega PX656-02D1 with Impexron GMBH in Lithuania . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The PX656-02D1 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of PX656-02D1 :
At Impexron GMBH , we offer the PX656-02D1 at competitive prices and with the fastest delivery times across Lithuania . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the PX656-02D1 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Omega products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
