BRAND | Pepperl-Fuchs |
Product | OBT20-R102-P1-IO-V31-F |
Internal code | IMP4930109 |
Custom code | 8536 5019 |
Technical specification | Description: Triangulation sensor (BGS) Product Type Code: OBT20-R102-P1-IO-V31-F EAN Number: 4050143407828 P+F Part number: 267075-100597 Detection range: 7 ... 20 mm Light source: LED Light type: modulated visible red light Signal output: 1 push-pull (4 in 1) output, short-circuit protected, reverse polarity protected, overvoltage protected Interface type: IO-Link ( via C/Q = pin 4 ) Switching type: C/Q - Pin4: NPN normally closed / dark-on, PNP normally open / light-on, IO-Link /Q - Pin2: open Connection: M8 x 1 connector, 4-pin Operating voltage: 10 ... 30 V DC Ambient temperature: -40 ... 60 °C (-40 ... 140 °F) REACH EC 1907/2006: -(0100) -(0074) |
Discover the superior quality and performance of the Pepperl-Fuchs OBT20-R102-P1-IO-V31-F with Impexron GMBH in Lithuania . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The OBT20-R102-P1-IO-V31-F is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of OBT20-R102-P1-IO-V31-F :
At Impexron GMBH , we offer the OBT20-R102-P1-IO-V31-F at competitive prices and with the fastest delivery times across Lithuania . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the OBT20-R102-P1-IO-V31-F ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Pepperl-Fuchs products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Y-Verteiler
P/N:221647, Type:VAZ-HORN-70MM-0..100DBA-8TONE
Akustische Signalisierung
P/N:221667, Type:VOS412-BIS-90-WH-F119
Vision Sensor
Steckerabdeckung
p/n: 221826, Type: ML100-55/103/115a
Photovoltaic sensor
p/n: 221827, Type: ML100-55/103/115b
retroreflective sensor
p/n: 221852, Type: V1-G-OR1M-POC-V1-G
Verbindungskabel
p/n: 221853, Type: V1-G-OR5M-POC-V1-G
Verbindungskabel
p/n: 221854, Type: V1-G-OR10M-POC-V1-G
Verbindungskabel
p/n: 221855, Type: V1-G-OR1M-POC
Kabeldose
p/n: 221856, Type: V1-G-OR2M-POC
cable socket
p/n: 221857, Type: V1-G-OR5M-POC
Kabeldose
p/n: 221858, Type: V1-G-OR10M-POC
Kabeldose
p/n: 221859, Type: V1-G-OR1M-POC-V1-W
Verbindungskabel
p/n: 221860, Type: V1-G-OR2M-POC-V1-W
Verbindungskabel
p/n: 221937, Type: MH-BT-F03-M5
Montageset
p/n: 221938, Type: MH-BT-F04-M5
Montageset
Montageset
p/n: 221940, Type: MH-BT-F05-M5
Montageset
p/n: 221941, Type: MH-BT-F05-M6
Montageset
Montageset
p/n: 221943, Type: MH-BT-F07-M6
Montageset
p/n: 221944, Type: MH-BT-F07-M8
Montageset
Montageset
p/n: 221946, Type: MH-BT-F10-M10
Montageset
P/N:221947, Type:MH-BT-F10-M12
Montageset
P/N:221948, Type:MH-BT-F12-M10
Montageset
P/N:222123, Type:FD0-BI-EX12.PA
Sensoranschaltung
P/N:222228, Type:V1-G-BK5M-PUR-U-Y222228
Kabeldose
p/n: 222237, Type: V31-WM-A2-10M-PUR-V1-G
Verbindungskabel
