| BRAND | Interroll |
| Product | MI-DM0138 DM1383-C8213B0E0MBD-507mm |
| Description | motor |
| Internal code | IMP4471152 |
| Technical specification | Product name DM 0138 Asynchronous 3-phase IP 69 K degree of protection Tube length (SL) 500.0 mm Drum width (FW) 507.0 mm Installation length (EL/LW/BF) 530.0 mm Total axle length (AGL) 580.0 mm power 1,000 W Winding number of poles 2 Torque [Nm] 190.5 strip tensile force 2,412 N Gear ratio (i) 63.00 Gearbox material description cast iron: GGG-40 Velocity at frequency of 1 0.37 m/s Frequency 1 50 Hz external connection diagram M34 high voltage 400 V low voltage 230 V Rated current, high voltage 2.04 A rated current, low voltage 3.54 A Velocity at frequency 2 0.45 m/s Frequency 2 60 Hz high voltage 2 460 V low voltage 2 230 V Tube material stainless steel: 1.4301/304 pipe diameter (A) 158.0 mm pipe diameter (B) 158.0 mm Profiled tube shape Tube option type INTRALOX series TD8050 Number of teeth (Z) 10 Coating material polyurethane coating hardness 82 Shore D coating color white Lid A design standard Lid B version standard lid A material stainless steel: 1.4305/303 lid B material stainless steel: 1.4305/303 Shaft A design replacement 138i standard Shaft B version replacement 138i standard Shaft A Material stainless steel: 1.4305/303 Shaft B Material stainless steel: 1.4305/303 Shaft A Diameter (D) 30.0 mm Shaft B Diameter (D) 30.0 mm Shaft A KeyArea width (F) 20.0 mm Shaft B Key.Area width (F) 20.0 mm Wave A Key.Face length (C) 25.0 mm Wave B Key.Face length (C) 25.0 mm Oil type synthetic food oil Electrical connection elbow fitting electric. Connection material stainless steel: 1.4305/303 Power cable length 5.0 m Power cable type unshielded; non-halogen free |
Discover the superior quality and performance of the Interroll MI-DM0138 DM1383-C8213B0E0MBD-507mm with Impexron GMBH in Lithuania . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The MI-DM0138 DM1383-C8213B0E0MBD-507mm is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of MI-DM0138 DM1383-C8213B0E0MBD-507mm :
At Impexron GMBH , we offer the MI-DM0138 DM1383-C8213B0E0MBD-507mm at competitive prices and with the fastest delivery times across Lithuania . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the MI-DM0138 DM1383-C8213B0E0MBD-507mm ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Interroll products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
