BRAND | Sirai |
Product | D132VEDU130S5A |
Description | solenoid valve |
Internal code | IMP4785461 |
Custom code | 84818099 |
Technical specification | D132V23-Z130A-G1/2-DN9.0-230VAC Number of paths 2-way (2/2) Control type directly actuated Switching function closed without a power supply (N.C.) Model SIRAI/ASCO series D132 Material plastic Special feature Without manual operation, media separation with separating lever ATEX approval no approval Connection size 1/2 inch Connection type G thread DIN 259/ISO 228 Nominal diameter DN9 Voltage 230 volts AC (~) Power consumption 24VA Electrical connection device plug type A Class F coil class FKM/FPM gasket Nominal pressure 1.6bar Medium temperature -10°C to +100°C Opening time 30 msec Closing time 30 msec Kv/flow factor 1.60 m³/h Medium viscosity 37 cSt Overall length 119.2 mm |
Please Contact Us to Order to offer competitive prices and delivery time for Sirai - D132VEDU130S5A solenoid valve number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
