MI-DM0138 DM1383-ASL13B0E5VFA-707mm - Interroll Lithuania Sales

BRAND	Interroll
Product	MI-DM0138 DM1383-ASL13B0E5VFA-707mm
Internal code	IMP4463001
Technical specification	Product name DM 0138 Asynchronous 3-phase Protection level: IP 69K Tube length (SL) 700.0 mm Drum width (FW) 707.0 mm Installation length (EL/LW/BF) 730.0 mm Axle total length (AGL) 780.0 mm Power: 370 W Winding number of poles 4 Torque [Nm] 112.5 Belt tensile force 1,562 N Gear ratio (i) 49.20 Gearbox material designation cast iron: GGG-40 Speed at frequency 1 0.21 m/s Frequency 1 50 Hz external connection diagram M45 high voltage 400 V low voltage 230 V Rated current, high voltage 1.01 A rated current, low voltage 1.74 A Speed at frequency 2 0.26 m/s frequency 2 60 Hz high voltage 2 460 V low voltage 2 230 V Stainless steel tube material: 1.4301/304 Pipe diameter (A) 144.0 mm Tube diameter (B) 142.0 mm Tube shape crowned (standard) pipe option type smooth rubber coating coating material NBR rubber coating Coating hardness: 70 shore A. coating color white coating process hot vulcanized Lid A design standard Lid B standard version Lid A material stainless steel: 1.4305/303 Lid B material stainless steel: 1.4305/303 Shaft A version replacement 138i standard Shaft B version replacement 138i standard Shaft A material stainless steel: 1.4305/303 Shaft B material stainless steel: 1.4305/303 Shaft A diameter (D) 30.0 mm Shaft B diameter (D) 30.0 mm Shaft A coil.Area width (F) 20.0 mm Shaft B key area width (F) 20.0 mm Shaft A cohes.Surface length (C) 25.0 mm Shaft B cohes.Surface length (C) 25.0 mm Oil type synthetic food oil Electrical connection terminal box Electrical Connection material polyamide 6+glass fiber

Please Contact Us to Order to offer competitive prices and delivery time for Interroll - MI-DM0138 DM1383-ASL13B0E5VFA-707mm number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
