BRAND | Jesco |
Product | MEMDOS LP 400 |
Internal code | IMP4449622 |
Custom code | 84135040 |
Technical specification | 104P15XXX-084 PVC/EPDM Engine diaphragm dosing pump Mathcode:0104P0400CAE21A5050C2EC2E Product: MEMDOS type: LP Flow rate: 390 l/h at 50/60 Hz versus max. 4.5 bar Dispense head and valves material: PVC Signal feedback: analog output 0/4 — 20 mA Electric drive: 230 V 1ph 50/60 Hz 0.55 kW (EC motor) Electrical connection: 1.8 m power cord with plug, Europe (at 230 V AC) Suction valve: DN15 spring loaded PVDF/EPDM (plate/seal) Pressure valve: DN15 spring loaded PVDF/EPDM (plate/seal) Suction connection material: PVC Suction connection: hose clamp connection Ø16 Pressure connection material: PVC Pressure connection: hose clamp connection Ø16 Functions: stroke frequency can be set precisely with keyboard Graphic display with multilingual menu analog input 0/4 — 20 mA pulse input (over- and reduction) Level input with pre- and main alarm Release input for external start/stop display of the flow rate in different units Limitation of maximum flow rate possible Hub feedback output batch dosing with interval and timer function dosing control inlet alarm relay output analog output 0/4 — 20 mA Dosing volume adjustment in ppm possible |
Please Contact Us to Order to offer competitive prices and delivery time for Jesco - MEMDOS LP 400 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
