P/N: 10231606, Type: MAGDOS LP 15 PVC/FPM - Jesco Lithuania Sales

BRAND	Jesco
Product	P/N: 10231606, Type: MAGDOS LP 15 PVC/FPM
Description	Solenoid Diaphragm Dosing Pump
Internal code	IMP3763235
Weight	3.2
Custom code	84135040
Technical specification	Solenoid Diaphragm Dosing Pump Mathcode: 0102P0150BC031A2K2KC1ZC1Z00 Solenoid-Diaphragm Dosing Pump Product: MAGDOS Type: LP Delivery rate: 13 l/h at 3 bar - 15 l/h at 1 bar Capacity adjustment: Stroke frequency adjustable: 0 - 250 strokes/min Material dosing head and valves: PVC Control unit: 100 - 240 V AC, 50/60 Hz Electrical connection: 1.8 m mains cable with plug, Europe Suction valve DN4: Double-ball ceramic/PVDF/FPM (ball/seat/gasket) Discharge valve DN4: Double-ball ceramic/PVDF/FPM (ball/seat/gasket) Material suction connection: PVC Suction connection: Hose clamp connection set 4/6, 6/9 and 6/12 Material discharge connection: PVC Discharge connection: Hose clamp connection set 4/6, 6/9 and 6/12 Dosing head arrangement: Floor mounting Functions Stroke frequency can be precisely adjusted via the keyboard Graphic display with multi-language menu Analogue input and pulse input (increase and reduction) Level input with early warning and main alarm Release input for external start/stop Supply amount displayed in various units Maximum delivery rate can be limited Energy-saving "Eco-mode" is available Stroke feedback output Alarm relay output Batch dosing with interval and timer functions Dosing control input Diaphragm failure input for leak monitoring Dosing quantity adjustment possible in ppm Option: without

Please Contact Us to Order to offer competitive prices and delivery time for Jesco - P/N: 10231606, Type: MAGDOS LP 15 PVC/FPM Solenoid Diaphragm Dosing Pump number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.
