LR8515 - Hioki Lithuania Sales

BRAND	Hioki
Product	LR8515
Description	WIRELESS VOLTAGE/TEMP LOGGER
Internal code	IMP796483
Weight	1
Technical specification	Functionality [Used as standalone product (Data collected manually) ] Windows PC or Windows tablet (CD-R with software included) Android smartphone or Android tablet terminal (Software can be downloaded free of charge from Google Play.) Communication range varies with the performance of the computer or tablet (up to a line-of-sight distance of roughly 30 m) [Used as logging module (Real-time measurement) ] Device can be used as an LR8410 logging module to record and display data in real time and to control up to 7 units, Communication distance: 30 m Number of channels 2 ch (isolated; select voltage of thermocouple for each channel), Input terminals: M3 screw type terminal block Measurement items Voltage/ Thermocouple (K, T) Maximum input voltage ±50 V DC, Max. inter-channel voltage 60 V DC Measurement range [Voltage] ±50 mV to ±50 V , Max. resolution 0.01 mV [Thermocouple] -200 ˚C to 999.9 ˚C, Thermocouples (K, T), Max. resolution 0.1 ˚C Measurement accuracy [Voltage] ±0.05 mV (50 mV range) [Thermocouple] ±0.8 ˚C (Thermocouple K -100 ˚C to 999.9 ˚C) Reference junction compensation: Switchable between internal and external Reference junction compensation accuracy: ±0.5 ˚C (When using internal compensation, add to thermocouple measurement accuracy.) Temperature characteristics: Add (measurement accuracy × 0.1) / ˚C to measurement accuracy. Display items Measurement value, date, time, number of recorded data, maximum value, minimum value, and average value Functions Alarm, Scaling, Recording operation hold function, Erroneous operation prevention, Comment recording function, Power saving function, Authentication function, Free run Recording [Capacity] 500,000 data items for each channel [Mode] Instantaneous value [Interval] 0.1 to 30 sec, 1 to 60 min, 16 selections Power source AC Adapter Z2003 (AC100 V to 240 V, 50 Hz/60 Hz), AA alkaline batteries (LR6) ×2, External power DC5 V to 13.5 V (can also be supplied from USB bus power, with a conversion cable) Continuous operating time ([Capacity] 500,000 data items for each channel) (23˚C) 2.5 months (Recording interval of 1 min, Bluetooth® OFF), 7 days (Recording interval of 1 sec, Bluetooth® ON), 2 days (Recording interval of 0.1 sec, during real-time measurement with the LR8410) Dimensions and mass 85 mm (3.35 in) W × 75 mm (2.95 in) H × 38 mm (1.50 in) D, 126 g (4.4 oz) (Not including the battery)

Please Contact Us to Order to offer competitive prices and delivery time for Hioki - LR8515 WIRELESS VOLTAGE/TEMP LOGGER number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
