LPRI-025D-07-M01-SCB-G-A1-L - Binder Lithuania Sales

BRAND	Binder
Product	LPRI-025D-07-M01-SCB-G-A1-L
Description	low pressure reducer in stainless steel,
Internal code	IMP4733786
Technical specification	INSTRUM — low pressure reducer in stainless steel, In-line design, DN25 Flange connection in accordance with EN1092-1, Form B1, DN25, PN16 Seat: Ø7 mm, control pressure: 0.2-1.0 bar materials: case/inner parts: 1.4435; Seat seal: FFKM FDA; membrane: PTFE FDA + FKM Option -A1: ATEX version (Ex II 3G c IIA T4 — zone 1) in accordance with 2014/34/EU Option -G: incl. pressure gauge connection G1/4” option -L: Adjust & seal, INSTRUM —L: Factory adjustment and sealing P1:3.0 barg, P2 (=SET): 500 mbarg Indicate the installation position for settings of less than 200 mbar Installation position: vertical (typical) or horizontal Additional specification data Flow rate (set/max): 30/ approx. 70 Nm³/h

Please Contact Us to Order to offer competitive prices and delivery time for Binder - LPRI-025D-07-M01-SCB-G-A1-L low pressure reducer in stainless steel, number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.
