LD 1 PVC/FPM (10241002) - Jesco Lithuania Sales

BRAND	Jesco
Product	LD 1 PVC/FPM (10241002)
Internal code	IMP3340905
Weight	3.2
Technical specification	MAGDOS LD 1 PVC/FPM Solenoid Diaphragm Dosing Pump Matchcode: 0102D0010BC011A2K2KC1ZC1Z0 Customs Tariff No.: 84135040 Net Weight: 3,2 kg Control unit: 230 V AC, 50/60 Hz Electrical connection: 1.8 m mains cable with plug, Europe (for 230 V AC) Suction valve DN3: Double-ball ceramic/PVDF/FPM (ball/seat/gasket) Discharge Valve DN3: Double-ball ceramic/PVDF/FPM (ball/seat/gasket) Material suction connection: PVC Suction connection: Hose clamp connection set 4/6, 6/9 and 6/12 Material discharge connection: PVC Discharge connection: Hose clamp connection set 4/6, 6/9 and 6/12 Dosing head arrangement: Floor mounting Functions Stroke frequency can be precisely adjusted via the keyboard Graphic display Pulse input (increase and reduction) with connection cable Level input with early warning and main alarm Release input for external start/stop Solenoid-Diaphragm Dosing Pump Product: MAGDOS Type: LD Delivery rate: 0.76 l/h at 16 bar - 1.1 l/h at 8 bar Capacity adjustment: Stroke frequency adjustable: up to 250 strokes/min Material dosing head and valves: PVC

Please Contact Us to Order to offer competitive prices and delivery time for Jesco - LD 1 PVC/FPM (10241002) number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.
