KP75-MB/2-M12K - HIMMEL Lithuania Sales

BRAND	HIMMEL
Product	KP75-MB/2-M12K
Description	Flat Motor
Internal code	IMP4495209
Technical specification	number P-646189/1 Motor and gearbox with protection class IP64 (based on ATEX class II 3D Ex tc IIIB T300°C Dc - IP64). Dimension sheet: 1NJ001659 K model line/Design series: K75 Type/type: KP75-MB/2-M12K K-dimension sheet/dimension sheet: 1NJ001659 Color/colour: RAL 7031 blue grey 2K/blue grey 2K-PUR Type /mounting position: V5 K-mounting sides: one-sided foot machining Degree of protection/protection class: IP64 K-rating plate: adhesive label 90 x 60 /adhesive label 90 x 60 nameplate logo: SKY Ambient temperature/Ta [°C]: -20/+40 Output Variant: Spiral cone angle gearbox i = 1:1 V140 W.Shaft diameter [mm]: 30 W.Length/shaft length [mm]: 156 (middle foot bore to middle of gearbox/center foot fetch to center gear) Shaft thread: M16-L.H.+M12-R.H. K-flange discs Ø/ external diameter flange [mm]: 140 K-tool width [mm]: min. 2/max. 5 AS/Bearing-AS bearing (DE): Double bearing [radially reinforced]/double bearing [radial reinforcement] BS/Bearing-BS (NDE) bearing: Simple bearing K-elec. connection type/elec. connection mode: terminal box/ terminal box KK material/ terminal box material: aluminum/ aluminum KK location/terminal box position: 2DK KK screw connection/gland: (2x) -M25x1.5 + (1x) -M12x1.5 K-Gearbox Type/ K-Gear Type: Right Angle Gear/ Angular Gear V140 translation/ratio [i]: 1.00 Gearbox/Gear position: POS11 Oil quantity [l]: 0.30 Type of oil: CLP PAO 68 Synth.oil Electrical design/electrical design: CE Number of phases: 3 ~ Number of poles/poles: 2 Rated power/nominal power [kW]: 7.5 Nominal engine speed/ motor speed nom. [1/rpm]: 2880 Nominal frequency [Hz]: 50 Rated voltage/nominal voltage [V]: 400 Nominal current In [A]: 15.2 cosPHI /CosPHI: 0.86 Circuit/ Wiring: S102 (D) Duty operating mode: S 6-60% Type of supply/power supply: mains operation/mains operation Winding protection/motor protector: PTC 130°C Insulation class: F Motor connection diagram: A0114000. Wiring diagram installations 1/Con. diagram compon. 1: A01TP000 Brake type: M12K [12 Nm] (L8) Brake supply voltage [V]: 400 Connection: on the clipboard/on terminal block Brake 1 connection diagram brake 1: A01BA003

Please Contact Us to Order to offer competitive prices and delivery time for HIMMEL - KP75-MB/2-M12K Flat Motor number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
