BRAND | HIMMEL |
Product | KH112-SB/8U M10-RH / 2130000139 |
Description | Three-phase motor |
Internal code | IMP4425393 |
Technical specification | KH112-SB/8U M10-RH Like number P-652610/19 Weight approx. 108.0 kg + packaging Dimension sheet: 2NJ000205 K-model series/design series: K112 Type/type: KH112-SB/8U K-size sheet/dimension sheet: 2NJ000205 Colour: RAL 1012 lemon yellow 2K/lemon yellow 2K-PUR Design/mounting position: B3 K-mounting sides: one-sided foot machining Protection class: IP54 K-rating plate/name plate: adhesive label 90x60 /adhesive label 90x60 Rating plate logo/name plate logo: SKY Ambient temperature/ Ambient temperature /Ta [°C]: -20/+40 Output variant/Output variant: Shaft with spring fit/Shaft with parallel key W.diameter/shaft diameter [mm]: 38 W. length/shaft length [mm]: 80 (free shaft end) Shaft thread/shaft thread: M10-RH Storage AS/Bearing-AS (DE): simple bearing Bearing BS/Bearing-BS (NDE): simple bearing KK version/Terminal box type: Terminal box/Terminal box KK material/Terminal box material: aluminum/aluminum KK location/Terminal box position: 3DK KK screw connection/gland: (2x) -M25x1.5 Label/Approval|Identification/Certification: CE Number of phases: 3~ It works. ETA to 100 in%/Efficiency ETA to 100 in%: 85.3 Number of poles/poles: 8 Rated power/nominal power [kW]: 5.8 Nominal motor speed/Nominal motor speed [1/min; rpm]: 1265 Rated frequency/ Nominal frequency [Hz]: 87 Rated voltage/nominal voltage [V]: 400 Rated current/Nominal current In [A]: 14.4 CosPhi/CosPHI: 0.68 Circuit/ Wiring: S102 (D) Operating mode/Duty type: S1 Type of supply/power supply: FU-operation/ inverter duty Supply type/power supply CSA/UL: inverter duty Drive protection/motor protection (IEC60034-25): to be guaranteed by system managers/to be Guaranteed by System Manager Winding protector/ Motor protector: PTC 160°C Insulation class: F Ventilation type CSA/UL: TENV Motor circuit diagram/Motor connection diagram: A0102000 Circuit diagram built-in 1/Con. diagram compon. 1: A01TP000 |
Please Contact Us to Order to offer competitive prices and delivery time for HIMMEL - KH112-SB/8U M10-RH / 2130000139 Three-phase motor number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
