BRAND | Interroll |
Product | MI-DL0113 DL1131-AAA0AD02VJSC |
Description | DRUM MOTOR |
Internal code | IMP4798018 |
Technical specification | 279 mm Product name DL 0113 Asynchronous 1-phase Certification CRUus UL Certified Degree of protection IP 66 Tube length (SL) 257.0 mm Drum width (FW) 279.0 mm Installation length (EL/LW/BF) 285.0 mm Overall axle length (AGL) 325.0 mm Power 60 W Number of pins 4 windings Torque [Nm] 11.8 Belt pull force 208 N Gear ratio (i) 38.51 Speed at frequency 1 0.25 m/s Frequency 1 60 Hz external connection diagram E10 high voltage 115 V Nominal current, high voltage 1.50 A Steel pipe material: St37-2/AISI 1015 Tube diameter (A) 113.3 mm Tube diameter (B) 112.2 mm Spherical tube shape (standard) Cover A Material ALU EN-AC44300/AL230 Cover B Material ALU EN-AC44300/AL230 Cap A Material aluminum Cap B Material aluminum Cap A diameter 35.0 mm Cap B diameter 35.0 mm Cap A key surface width 21.0 mm Cap B key surface width 21.0 mm Cap A key surface length 20.0 mm Cap B key surface length 20.0 mm Oil type mineral oil Electrical connection butt plate with cable slot Power cable length 3.0 m Power cable type unshielded; not halogen-free |
Please Contact Us to Order to offer competitive prices and delivery time for Interroll - MI-DL0113 DL1131-AAA0AD02VJSC DRUM MOTOR number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
