Home Foxboro (by Schneider Electric)IDP10-T22C21D

IDP10-T22C21D Foxboro (by Schneider Electric)

qr_logo

IDP10-T22C21D - Foxboro (by Schneider Electric) Lithuania Sales

BRAND	Foxboro (by Schneider Electric)
Product	IDP10-T22C21D
Description	COMPLETE UNIT, M.W.P.320 MBAR
Internal code	IMP311131
Weight	1
Technical specification	M1L1S22A-1C14 A-CIDP10 FUNCTION:Measures The Difference Between Two Pressures AndTransmits A Proportional Or Square Root (Flow) ElectricalSignal.T ELECTRONICS VERSION AND OUTPUT SIGNAL:Intelligent; Digital HART & 4 To 20 mA22 STRUCTURE CODE:316 ss Process Cover, 316L ss Sensor, Silicone Fill FluidC SPAN LIMITS:7 And 210 kPa, 28 And 840 inH2O, 70 And 2100 mbar2 PROCESS CONNECTOR: (Matl Same As Process Cover)1/2 NPT1 CONDUIT CONNECTION & HOUSING MATERIAL:1/2 NPT Conduit Connection, Both Sides, Aluminum HousingD ELECTRICAL SAFETY:ATEX Flameproof; II 2 GD EEx d IIC, Zone 1M1 OPTIONAL MODEL SUFFIX(ES) INCLUDED:Painted Steel Mounting Bracket With Plated Steel BoltsL1 OPTIONAL MODEL SUFFIX(ES) INCLUDED:Digital Indicator, Internal Pushbuttons, And WindowS2 OPTIONAL MODEL SUFFIX(ES) INCLUDED:SIL2 TUV Rhineland

Please Contact Us to Order to offer competitive prices and delivery time for Foxboro (by Schneider Electric) - IDP10-T22C21D COMPLETE UNIT, M.W.P.320 MBAR number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
