GWE0608PS/OS2-80mm - Welotec Lithuania Sales

BRAND	Welotec
Product	GWE0608PS/OS2-80mm
Description	Infrarotlicht Gabellichtschranke
Internal code	IMP1798550
Weight	0.8
Technical specification	General data: SeriesGWE TypeFork light sensor Light sourceInfrared light Wavelength880 nm SensorfunctionSwitch Connection typeM8 connector, 3-pin Sensitivity settingPotentiometer Measurement data: Minimum detectable objectØ 1.2 mm Repeat accuracy0.04 mm Outputs: Number of outputs1 Output circuitDigital (PNP-transistor) Output functionNO / NC (switchable) Switching hysteresis< 0.03 mm Switching frequency1 kHz Power supply: Power supply V DC10 - 30 V DC Load current typical35 mA Load current400 mA Short circuit protectionYes Voltage drop2.5 V at 200 mA Physical characteristics: Housing materialAluminium, black anodized Ingress protectionIP65 Environmental: Operating temperature range-10 - +60 °C

Please Contact Us to Order to offer competitive prices and delivery time for Welotec - GWE0608PS/OS2-80mm Infrarotlicht Gabellichtschranke number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
