PGLG--72VVVB---GG--M8112M - Ultra Pompe S.r.l. Lithuania Sales

BRAND	Ultra Pompe S.r.l.
Product	PGLG--72VVVB---GG--M8112M
Description	Gear pump
Internal code	IMP3361881
Weight	27
Custom code	84136031
Technical specification	GL 72 VB with lantern and coupling G series gear pump Main body: Cast iron G25 B5 lantern mounting Complete of lantern and coupling (no drive) Displacement 72 cc/rev Mechanical seal: stainless steel/carbon graphite/FPM External lip seal: FPM - Gasket: FPM Standard safety relief valve installed (oriented for right rotation) Rotors: Steel 39NiCrMo3 Nitriding process Bearings: steel/PTFE To be coupled to electric motor 1,5 KW 8 Poles B3/B5 230/400/50Hz IP55 class F 112M Rated speed: 700 rpm Theoric rated delivery (1 bar, 220 cSt): 50,4 l/min Design pressure: 30 bar Operating pressure and viscosity limited by motor power Operating pressure: 4 bar Operating viscosity: 150...350 cst Operating temperature: -10...+120°C

Please Contact Us to Order to offer competitive prices and delivery time for Ultra Pompe S.r.l. - PGLG--72VVVB---GG--M8112M Gear pump number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.
