FZA31-G80M4-D15N /2230010794 HIMMEL technologies

Buy FZA31-G80M4-D15N /2230010794 from HIMMEL technologies in Lithuania

BRAND	HIMMEL technologies
Product	FZA31-G80M4-D15N /2230010794
Description	Offset geared motor
Internal code	IMP4492148
Custom code	85015220
Technical specification	Dimension sheet: FA02 Gearbox design/Type: HIMMEL® offset geared motor/ HIMMEL® parallel shaft mounted gear engine Transmission type/ Type: FZA31-G80M4-D15N Dimension/dimension sheet: FA02 Output speed [1/min; 1/rpm]: 129.00//157.00 translation/ratio [i]: 10.88 Color/colour: RAL 9011 graph-black, matt/graphite black Degree of protection/protection class: IP54 Type /mounting position: H-02-A Output torque [Nm]: 55.7//54.7 Output direction of rotation: right/right Output shaft gearbox [mm; inch]: H30x120 Gearbox/Bearing Bearing: assigned bearings Type of oil: CLP 220 Miner.oil Oil quantity [l]: 0.80 Shaft material: C45 Gearbox sealing/ Sealing: shaft seal ring (WDR)/shaft seal ring Electrical design/electrical design: CE Number of poles: 4 Nominal frequency [Hz]: 50/60 Rated voltage/nominal voltage [V]: 220-240/380-420//254-277/440-480 Circuit/ Wiring: S100//S100 (D/Y//D/Y) Rated power/ nominal power [kW]: 0.75 //0.9 Nominal engine speed/motor speed nom. [1/rpm]: 1400//1710 Nominal current In [A]: 3.50/2.00 CosPHI/CosPHI: 0.75//0.75 KK location/terminal box position: 2C KK version/ terminal box type: plastic/plastic Winding protection/motor protector: without/without Output shaft engine/output shaft [mm; inch]: V12x18.5 Engine sealing: normal/normal. Insulation class: F Duty operating mode: S 3-75% Fan/ fan: plastic/plastic brake supply voltage [V]: 220-240/380-420

Discover the superior quality and performance of the HIMMEL technologies FZA31-G80M4-D15N /2230010794 with Impexron GMBH in Lithuania . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.

The FZA31-G80M4-D15N /2230010794 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.

Key Features of FZA31-G80M4-D15N /2230010794 :

High Performance: Engineered to deliver exceptional results.
Durable Construction: Built with high-quality materials for long-lasting use.
Innovative Design: Incorporates the latest technology for enhanced efficiency.
Cost-Effective: Offers great value for money with competitive pricing.

At Impexron GMBH , we offer the FZA31-G80M4-D15N /2230010794 at competitive prices and with the fastest delivery times across Lithuania . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.

Why Choose Impexron GMBH ?

Expert Assistance: Get help from our knowledgeable team for all your product-related questions.
Competitive Prices: We offer some of the best prices in the market.
Fast Delivery: Benefit from our efficient delivery network for quick turnaround times.
Customer Satisfaction: Our commitment to customer service ensures a great buying experience.

Get Your Quote Today! Ready to enhance your operations with the FZA31-G80M4-D15N /2230010794 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.

Important Notice: While we supply HIMMEL technologies products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
