BRAND | Valco |
Product | FCM5-1.15.GV.12P |
Description | Fixed-calibration flow switch |
Internal code | IMP4741616 |
Technical specification | <vertical mounting - flow from bottom to top> Brass body 1/2" Gas-M process connections Piston sensitive element Max working pressure 250 bar Max working temperature 90°C Fixed calibration, see available calibrations as per the technical bulletin Maximum recommended flow 25 l/min H2O Pressure loss at the maximum recommended flow rate 0.5 bar Replaceable and replaceable electric head - without removing the flow switch from the pipeline Contact Reed NA Maximum electrical loads: 300VCA-DC/70VA/50W/0.5A Electrical output: Faston 6.3 km Replaceable and replaceable electric head - without removing the flow switch Degree of protection IP00 nos. cod. 00.0001.0673 |
Please Contact Us to Order to offer competitive prices and delivery time for Valco - FCM5-1.15.GV.12P Fixed-calibration flow switch number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
