BRAND	Warex
Product	DN 400
Description	Butterfly valve
Internal code	IMP3297714
Weight	1
Technical specification	Overall length: 67 mm Abandoned. Manual transmission, type WH 81/AB232-13 1000 Nm/incl. handwheel for medium: bulk material Properties: free-flowing, chemically neutral, not prone to baking Work pressure: pressureless Maximum allowable operating pressure: < 0.5 bar (Ps) MAWP (Note: MAWP = Ausl. -Pressure) Operating temperature: 0°C to +60°C (Ts) MAWT Surround. -Temp.: 0°C to +50°C (Ta) Explosion protection: not required evaluation of butterfly valves in accordance with DGRL 2014/68/EU, Diagram 7, certified module A2. The valves are not subject to conformity assessment. butterfly valve, type DKZ 110, to clamp between flanges according to EN 1092, PN 10 Silumin housing White NBR sealing collar can be replaced in the housing Food-safe, in accordance with Regulation (EC) No 1935/2004 stainless steel flap disc 1.4301 1.4057 or higher grade stainless steel shafts Shaft sealing with O-rings Wave storage in MS sockets Test pressure: design pressure x 1.1 bar for tightness

Please Contact Us to Order to offer competitive prices and delivery time for Warex - DN 400 Butterfly valve number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.
