BRAND | Demag |
Product | DIC-4-007-C-0000-13 |
Description | Frequency inverter |
Internal code | IMP4312784 |
Technical specification | Digital two-point inverter with voltage intermediate circuit for single and four-quadrant operation with integrated brake chopper for resistance braking. Cold plate device (separate heat sink/cooling surface required additionally); printed circuit boards with protective coating. Integrated safety function “safe torque off” (STO) according to EN 61800-5-2. Meets cat.3, PLD according to EN ISO 13849-1 and SIL2 according to IEC 61508. * Technical data: Mains voltage: 3 x 380 - 480 V (+10/-15%) Power frequency: 50/60 Hz (+10/-10%) Motorshaft power: 3.00 kW Output voltage: 3 x 0 - mains voltage V Output frequency: 0 - 300 Hz depending on switching frequency Output current: 7.8 A at 2 to 8kHz overload factor at 2 and 4kHz: 1.5 for 60 s; 2.0 for 10 s (cycle 10 min) Modulation frequencies: 2, 4, 8, 12, 16 kHz (note current reduction) Protection class: IP 20 Operating temperature: 0 - 40 °C installation height: 0 - 1000 m Dimensions: 60/250/175 mm width/height/depth Installation position: vertical Therm. Heat sink resistance: 0.31 K/W Technical data at operating point mains voltage: 3 x 400 V Output current: 7.8 A at 40°C ambient temperature and 4 kHz modulation frequency Overload factor: 1.5 for 60 s (cycle 10 min.) 2.0 for 10 s (cycle 10 min.) Operating temperature: 0 °C/40 °C installation height: 0/1000 m specification: type: Dedrive Compact STO DIC-4-007-C-0000-13 - Keypad KP 500 (programming unit) - CD-ROM 21368644 (project planning guide and other product documentation) |
Please Contact Us to Order to offer competitive prices and delivery time for Demag - DIC-4-007-C-0000-13 Frequency inverter number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
