| BRAND | Demag |
| Product | DIC-4-006-E-0000-03 |
| Description | Dedrive Compact STO frequency inverter |
| Internal code | IMP251712 |
| Weight | 1.7 |
| Technical specification | Replaced Material No 16040084 Demag Dedrive Compact STO frequency inverter Digital two-point inverter with voltage intermediate circuit for one and four-quadrant operation with integrated brake chopper for resistance braking. Integrated safety function “Safely switched off moment” (Safe Torque Off, STO) in accordance with EN 61800-5-2. Meets the requisitions Cat.3, PLd according to EN ISO 13849-1 and SIL2 according to IEC 61508. Technical data: Line voltage: 3 x 380 - 480 V (+10/-15%) Line frequency: 50/60 Hz (+10/-10%) Motor shaft power: 2.20 kW Output voltage: 3 x 0 - line voltage V Output frequency: 0 - 300 Hz depending on switching frequency Output current: 5.8 A at 2 to 8kHz Overload factor at 2 and 4kHz: 1.5 for 60 s; 2.0 for 10 s (cycle 10 min) Modulation frequencies: 2, 4, 8, 12, 16 kHz (Note the power reduction Integrated safety function “Safely switched off moment” (Safe Torque Off, STO) in accordance with EN 61800-5-2. Meets the requirements of Cat.3, PLd according to EN ISO 13849-1 and SIL2 in accordance with IEC 61508. Technical data: Line voltage: 3 x 380 - 480 V (+10/-15%) Line frequency: 50/60 Hz (+10/-10%) Motor shaft power: 2.20 kW Output voltage: 3 x 0 - line voltage V Output frequency: 0 - 300 Hz depending on switching frequency Output current: 5.8 A at 2 to 8kHz Overload factor at 2 and 4kHz: 1.5 for 60 s; 2.0 for 10 s (cycle 10 min) Modulation frequencies: 2, 4, 8, 12, 16 kHz (current reduction notice Protection class: IP 20 operating temperature: 0 - 40 °C Installation height: 0 - 1000 m dimensions: 60/250/175 mm width/height/depth Installation position: vertical Net weight: approx. 1.7 kg Technical data at operating point Line voltage: 3 x 400 V Output current: 5.8 A at 40 °C ambient temperature and 4 kHz modulation frequency Overload factor: 1.5 for 60 s (cycle 10 min.) 2.0 for 10 s (cycle 10 min.) Operating temperature: 0 °C/40 °C Installation height: 0/1000 m Specification: Type: Dedrive Compact STO DIC-4-006-E-0000-03 - Keypad KP 500 (control unit) |
Discover the superior quality and performance of the Demag DIC-4-006-E-0000-03 with Impexron GMBH in Lithuania . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The DIC-4-006-E-0000-03 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of DIC-4-006-E-0000-03 :
At Impexron GMBH , we offer the DIC-4-006-E-0000-03 at competitive prices and with the fastest delivery times across Lithuania . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the DIC-4-006-E-0000-03 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Demag products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy DIC-4-006-E-0000-03 by Demag in Lithuania?
You can purchase DIC-4-006-E-0000-03 by Demag from Impexron GMBH. We serve customers across Lithuania, offering competitive prices and reliable service.
What is the price of the DIC-4-006-E-0000-03?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Demag in Lithuania?
While we are not the official distributor or seller of Demag in Lithuania, we source our products from reliable channels and offer you original Demag equipment at competitive prices.
How can I access DIC-4-006-E-0000-03 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for DIC-4-006-E-0000-03 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for DIC-4-006-E-0000-03?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
