DF24A1C5H1E74F2ER7U1XZM2VLR250W00VR - Mollet Lithuania Sales

BRAND	Mollet
Product	DF24A1C5H1E74F2ER7U1XZM2VLR250W00VR
Description	Rotary vane level indicator
Internal code	IMP4792585
Custom code	9031 80 20
Technical specification	DF24 limit switch for bulk goods >0.5 t/m³ Full, empty and demand detectors for any installation position with long stainless steel support tube > >> with reinforced wing shaft <<< waves Ø 20 mm A1 aluminum compact housing, RAL 7001, protection class IP66 Ambient temperature at control head Ta -20°C... 70°C C5 operating voltage 24 V DC Signal contact 1 mA 4 V... 2 A 240 V~, potential-free changeover gold-plated contacts (multi-voltage and multi-current switch) H1 small dome in the device lid for function LEDs yellow=on/blue=full/green=empty E74 device heater 3.5 watts Ambient temperature at the control head -40°C... 70°C Bulk material temperature -45°C... 80°C P0 suitable for pressure in the vessel -0.5 bar... 5 bar F2E process connection flange F100 made of 1.4301 Dimensions 150x150, Lk170, 4xØ18 R7U1X shaft seal, filled PTFE, white FDA Speed of the measuring blade = 1 rpm, with reinforced spring Z stainless steel ball bearing M2V muffle-wing, reinforced, 90x40x2 mm Length >LF< = 70 mm LR250 support tube length >LR< = 250 mm W00 flange welded to the support tube W = 0° VR welded reinforcing ribs

Please Contact Us to Order to offer competitive prices and delivery time for Mollet - DF24A1C5H1E74F2ER7U1XZM2VLR250W00VR Rotary vane level indicator number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.
