BRAND | C.E. srl |
Product | C73-1SXB(QL2) |
Description | magnetic limit switch |
Internal code | IMP3836486 |
Technical specification | GO magnetic limit switch 70 series Mod. 73 passive type (without power supply and without reed contacts) - mechanical contact (snap action & dry contact): SPDT in palladium-silver - contact rating: 2A at 240V a.c. 4A at 120 V a.c. and 3A at 24V d.c. resistive load - sensitive distance: 2.5 mm. (with ferrous feedback) - differential (hysteresis): 0.5 mm. (with ferrous feedback) - response time: 8 milliseconds - working temperature: -50 ° C to + 105 ° C - casing: STAINLESS STEEL 316 - conduit connection: 1/2 ”NPT- M - Certifications (BVI14ATEX 0030 & IECEx EPS 14.0026): PRODUCT code C73-1 ***** ATEX Ex II 2 GD - Ex db IIC T6 / T5 Gb Ex t IIIC T85 ° C / T100 ° C Db IP66 / 67 IECEx Ex db IIC T6 / T5 Gb Ex tb IIIC T85 ° C / T100 ° C IP66 / 67 Tamb. from -40 ° C to + 75 ° C (T6) from -40 ° C to + 90 ° C (T5) - degree of protection: IP66 / 67 - PVC 105 ° C insulated connection conductors 900mm long. about. Cable exit on the bottom |
Please Contact Us to Order to offer competitive prices and delivery time for C.E. srl - C73-1SXB(QL2) magnetic limit switch number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
