4800317 - Micro-Epsilon (Eltrotec) Lithuania Sales

BRAND	Micro-Epsilon (Eltrotec)
Product	4800317
Description	Miniatur-Pyrometer
Internal code	IMP560724
Weight	1
Technical specification	1,000 pcs CSmi2W-SF15-C1 miniature pyrometer 195.00 195.00 Temperature measurement range: -40° to 1030°C Optical resolution: 15:1 Spectral range: 8 to 14 μm Measuring spot: 0.8 mm at a distance of 10 mm (optional with CF lens) Response Time: 30ms (90%) Temperature resolution: 0.1K System Accuracy: ±1.0% or ±1.5°C (whichever is greater) Reproducibility: ±0.75% or ±0.75 °C (whichever is greater) Temperature coefficient: ±0.05K/K or ±0.05%K Transmission: 0.100 to 1.100 (adjustable via software/optional) Signal processing: maximum and minimum value hold, mean value; advanced hold function with threshold and hysteresis Ambient temperature: -20°C - 120°C (sensor), -20°C - 75°C (controller) Storage temperature: -40°C - 85°C (sensor+controller) Supply: 5-30 VDC Outputs/Analog: 4-20 mA two-wire analog output (scalable via software/optional) Outputs/digital: alarm output (open collector) LED function: alarm display, automatic aim assistance, self-diagnosis, Temperature display (via temp. code) Protection class: IP65 (NEMA-4) (sensor head) Scope of delivery: Sensor with stainless steel housing (M12x1) incl. 2 mounting nuts, 1m sensor cable, controller integrated in the cable after 0.5m, operating instructions

Please Contact Us to Order to offer competitive prices and delivery time for Micro-Epsilon (Eltrotec) - 4800317 Miniatur-Pyrometer number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
