138743 / 2010 - Warex Lithuania Sales

BRAND	Warex
Product	138743 / 2010
Internal code	IMP4216642
Technical specification	for medium : air chemical not aggressive, not sticky working pressure : pressureless max. allowable working pressure : < 0,5 bar (Ps) MAWP (Note: MAWP = design pressure) max. allowable working temperature: 0° C to +40° C (Ts) MAWT ambient temp.: 0° C to +50° C (Ta) Ex-protection : not required Rating of butterfly-valves according PED/2014/68/EU, diagram 7 Certified module A2 The butterfly-valves are not subject to this conformity assessment Warex-butterfly valve, type: DKZ 110 for mounting between flanges, drilled in acc. to EN 1092, PN 10 body of silumin sealing element of EPDM black replaceable disc of stainless steel 1.4408 for DN 50...350, otherwise 1.4301 shaft of stainless steel 1.4057 or equivalent shaft sealing with O-rings bearing bush of brass test pressure: design pressure x 1,1 bar for tightness 5129b DN 500 face to face: 77 mm RC265DA fitted with pneumatic actuator type RC 265 DA - double acting - air supply necessary: 6 bar 401 with mounted 5/2 way solenoid-valve, Norgren Herion, type 2623077.3037 voltage: 24 V DC 1,6 W - Namur interface - protection IP 65 550 fitted with 2 micro switches, make: Crouzet, type: 83.161.301W2 10A, 300V AC, mounted in Vestamid- housing, with transparent cover, TCR housing 144/64/70 for disc position "open - closed" incl. mounting bracket Note:Products that contain brass or aluminum components can contain lead (Cas-no. 7439-92-1) in a concentration of over 0.1 percent by weight.

Please Contact Us to Order to offer competitive prices and delivery time for Warex - 138743 / 2010 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.
