MI-DL0113 DL1131-BAA0AD02DJSC-594mm - Interroll Lithuania Sales

BRAND	Interroll
Product	MI-DL0113 DL1131-BAA0AD02DJSC-594mm
Description	Motor
Internal code	IMP31715
Weight	1
Technical specification	Product name DL 0113 asynchronous 1-phase UL Approbation cruuS UL certified IP 66 protection Tube length (SL) 571.5 mm drum width (FW) 593.5 mm Installation length (EL/LW/BF) 599.5 mm Axis total length (AGL) 639.5 mm power 150 W winding number of pins 4 Torque [Nm] 29.5 Pulling force 520 N Gear ratio (i) 38.51 speed at frequency 1 0.25 m/s frequency 1 60 Hz external connection diagram E10 high voltage 115 V Rated current, high voltage 2.80A Pipe material steel: St37-2/AISI 1015 Pipe diameter (A) 113.3 mm Pipe diameter (B) 112.2 mm tube shape ballig (default) Lid A material ALU EN-AC44300/ AL230 Lid B material ALU EN-AC44300/ AL230 Cap A material aluminum Cap B material aluminum cap A diameter 35.0 mm cap B diameter 35.0 mm Cap A key face width 21.0 mm Cap B key face width 21.0 mm Cap A key surface length 20.0 mm Cap B key face length 20.0 mm Oil-type mineral oil Electrical connection butt cap with cable slot power cable length 3.0 m Unshielded power cable type; not halogen free

Please Contact Us to Order to offer competitive prices and delivery time for Interroll - MI-DL0113 DL1131-BAA0AD02DJSC-594mm Motor number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Lithuania Industrial products Market.
